Features
◇ 2 position 2 port reversing valve (normally open) with G1/8 and G1/4 air entry ports returns
the air signal through the vacuum switch to realize the air supply opening and closing and
energy saving.
◇ The small valve can control a large flow of compressed air.
| How to order | ||||
| ZVAA -G1F ① ② | ||||
| ① Series | ② Connection thread | |||
| ZVAA | G1F- G1/8 Female thread G2F- G1/4 Female thread | |||
| Technical parameters | |||||
| Air supply pressure (bar) | Output function | Ambient temperature (℃） | Material | ||
| 3.5-7 | NO(Normally open) | 0-60℃ | Aluminum alloy | ||
